960x240 Pixels 2.7 Inch Lcd Display Colors 262K Small TFT Display

  • 1
  • 2

Luminance : 230 cd/m2

Backlight Technology : LED

Operating Temperature : -20~+70℃

Backlight : White LED

Resolution : 960*240

Connectivity : RGB

Display Type : TFT

Pins Number : 40PINS

Place of Origin : china

Brand Name : BBI

Certification : ISO9001 RoHS

MOQ : 1000

Price : DISCUSSABLE

Packaging Details : CARTON

Delivery Time : 3-4WEEKS

Payment Terms : T/T

Supply Ability : 100000/MONTH

Contact Now

960x240 Pixels 2.7 Inch Lcd Display Colors 262K Small TFT Display


Product Details

Product Name: TFT Display
Size (inch): 2.7
Resolution: 960*240
Brightness 280
Interface: RGB 8bit
Driver Ic: ILI8191

Product Description

Screen Size 2.7 inch
Number of Pixel 960RGB(H)x240(V)
Display area 40.50(H)x54.00(V)mm
Pixel pitch 0.05625(H)x0.16875(V)mm
Pins 40 pins
Outline Dimension 46.20x63.10x2.38mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally White
Viewing Direction(eye) 6 0'CLOCK
Display Color 262K
Luminance(cd/m2) 230 nit
Contrast Ratio 600:01:00
Interface RGB 8bit
Back-light LED Side-light type
Drive IC ILI8961
Operation Temperature -30~80
Storage Temperature -30~80
